DIP8 通孔 单通道 高速 10 MB/s 逻辑门 光耦合器
制造商零件编号:6N137
封装形式： DIP-8
包装： TUBE
标准包装数量: 50
- No of Channels:1
- Isolation Voltage-Max:2500 V
- Output Voltage-Max:7 V
- Operating Temp-Max:85 °C
The 6N137 is a part of 6N13 series optocoupler. It has an operating temperature ranging from -40°C to +85°C and its available in DIP-8 package.
Features:
- Very high speed – 10 MBit/s
- Superior CMR – 10 kV/μs
- Double working voltage-480V
- Fan-out of 8 over -40°C to +85°C
- LogIC gate output
- Strobable output
- Wired OR-open collector
- U.L. recognized
Applications:
- Ground loop elimination
- LSTTL to TTL, LSTTL or 5-volt CMOS
- Line receiver, data transmission
- Data multiplexing
- Switching power supplies
- Pulse transformer replacement
- Computer-peripheral interface
6N137? 8-Pin DIP 10 Mbit/s Single-Channel High Speed Logic Gate Output Optocoupler
The6N137, HCPL2601, HCPL2611 single-channel and HCPL2630, HCPL2631 dual-channel optocouplers consist of a 850 nm AlGaAS LED, optically coupled to a very high speed integrated photo-detector logic gate with a strobable output. This output features an open collector, thereby permitting wired OR outputs. The coupled parameters are guaranteed over the temperature range of -40°C to +85°C. A maximum input signal of 5mA will provide a minimum output sink current of 13mA (fan out of 8).An internal noise shield provides superior common mode rejection of typically 10kV/μs. The HCPL2601 and HCPL2631 has a minimum CMR of 5kV/μs. The HCPL2611 has a minimum CMR of 10kV/μs.
Features
- Very high speed – 10 MBit/s
- Superior CMR – 10 kV/μs
- Double working voltage-480V
- Fan-out of 8 over -40°C to +85°C
- Logic gate output
- Strobable output
- Wired OR-open collector
- U.L. recognized (File # E90700)
Applications
- Energy Generation & Distribution
|
|
|
- Uninterruptible Power Supply
| |
Safety Agency Certificates
For additional information please visit theSafety Agency Certificates page.
- VDE 120915(803 K)
- UL E90700_1(959 K)
- CSA 1027742(2,361 K)
