| 型号 | EL817C | 厂家 | EVERLIGHT |
| 批号 | 2016 | 封装 | DIP4 |
现货供应原装正品亿光EVERLIGHT光耦EL817，原装正品，假一赔十！可提供各类认证证书,可开17%增票!
EVERLIGHT:EL817
单通道 35 V 5000 Vrms 光电耦合器 通孔
制造商零件编号:EL817
安装方法: Through Hole
封装形式： DIP-4
包装： TUBE
标准包装数量: 2500
产品亮点
- No of Channels:1
- Isolation Voltage-Max:5000 V
- Output Voltage-Max:35 V
- CTR-Min:50 %
- Operating Temp-Max:110 °C
The EL817 is a Single Channel Through Hole Photocoupler, available in DIP-6 Package.
The EL817 series contains a infrared emitting diode optICally coupLED to a phototransistor. It is packaged in a 4-pin DIP package and available in wide-lead spacing and SMD option.
Features:
- Current transfer ratio (CTR:MIN.50% at IF =5mA ,VCE =5V)
- High isolation voltage between input and output (Viso=5000 V rms )
- Compact dual-in-line package EL817*:1-channel type
- Pb free
- Options available:
- Leads with 0.4”(10.16mm) spacing (M Type)
- Leads bends for surface mounting (S and S1 Type)
- Tape and Reel of TypeⅠ for SMD(Add”TA” Suffix)
- Tape and Reel of TypeⅡ for SMD(Add”TB” Suffix)
- The tape is 16mm and is wound on a 33cm reel
- The product itself will remain within RoHS compliant version
Applications:
- Computer terminalsSystem appliances, measuring instruments
- Registers, copiers, automatic vending machines
- Signal transmission between circuits of different potentials and impedances
