| 型号 | PIC16F1947T-I/PT | 厂家 | MICROCHIP |
| 批号 | 2016 | 封装 | TQFP-64 |
PIC16 8位 1 kB RAM 表面贴装 CMOS 微控制器 TQFP-64
制造商零件编号:PIC16F1947-I/PT
安装方法:Surface Mount
封装形式：TQFP-64
包装：TRAY
标准包装数量:160
产品亮点
- Family Name:PIC16F
- Core Processor:PIC
- Program Memory Type:Flash
- Flash Size (Bytes):28 kB
- RAM Size:1 kB
- Speed:32 MHz
- No of I/O Lines:54
- InterfaceType / Connectivity:I2C / SPI / USART
- Peripherals:LCD Segments / I2C / SPI / USART / Watchdog / PWM / On-Chip-ADC / Analog Comparators
- Number Of Timers:5
- Supply Voltage:1.8 to 5.5 V
- Operating Temperature:-40 to +85 °C
- On-Chip ADC:17-chx10-bit
- Watchdog:1
PIC16F1947-I/PT is part of PIC16F mid-range family with a 8-Bit Microcontroller. It can sustain standard temperature ranges from -40°C to +85°C and has 64 pin in TQFP package. This device is lead free.
Features:
- Enhanced Mid-range Core with 49 Instruction, 16 Stack Levels
- Flash Program Memory with self read/write capability
- 184 LCD segment drive support
- Internal 32 MHz oscillator
- Integrated Capacitive mTouch Sensing Module
- 2xMI2C, 2xSPI, 2xEUSART w/auto baud
- 3 ECCP & 2 CCP (Enhanced/Capture Compare PWM)
- Comparators with selectable Voltage Reference
- 17 Channel 10b ADC with Voltage Reference
- 25 mA Source/Sink current I/O
- Four 8-bit Timers (TMR0/TMR2/TMR4/TMR6)
- One 16-bit Timer (TMR1)
- Extended Watchdog Timer (EWDT)
- Enhanced Power-On/Off-Reset
- Brown-Out Reset (BOR)
- In Circuit Serial Programming (ICSP)
- Wide Operating Voltage (1.8 V – 5.5 V)
- Low Power PIC16LF1947 variant (1.8 V – 3.6 V)
