pIC16位 MCu 带增强型内核 7kb 闪存 采用14引脚SOIC封装

制造商零件编号:PIC16F1824-I/SL
安装方法:Surface Mount
封装形式：SOIC-14
包装：TUBE
标准包装数量:57

产品亮点

The PIC16F1824-I/SL is a 8-Bit Microcontroller with 14-pin Flash. This devices contain an enhanced mid-range 8-bit CPU core. The CPU has 49 instructions, Interrupt capability includes automatic context saving.

The hardware stack is 16 levels deep and has Overflow and Underflow Reset capability. Direct, Indirect, and Relative addressing modes are available. Two File Select Registers (FSRs) provide the ability to read program and data memory.

Features:

• Enhanced Mid-range Core with 49 Instruction, 16 Stack Levels
• Flash Program Memory with self read/write capability
• Internal 32 MHz oscillator
• Integrated Capacitive mTouch Sensing Module
• Data Signal Modulator Module
• MI2C, SPI, EUSART w/auto baud
• 2 ECCP & 2 CCP (Enhanced/Capture Compare PWM)
• Comparators with selectable Voltage Reference
• 8 Channel 10b ADC with Voltage Reference
• 25 mA Source/Sink current I/O
• Four 8-bit Timers (TMR0/TMR2/TMR4/TMR6
• One 16-bit Timer (TMR1)
• Extended Watchdog Timer (EWDT)
• Enhanced Power-On/Off-Reset
• Brown-Out Reset (BOR)
• In Circuit Serial Programming (ICSP)
• On Board In-Circuit Debug
• Wide Operating Voltage (1.8 V – 5.5 V)
• Low Power PIC16LF182x variants (1.8 V – 3.6 V)
• Standby Current (PIC16LF182X): 30 nA @ 1.8 V, typical
